SN-50W
Short Description:
The SN series barrier terminal block comply with the international standard IEC60947-7-1/, EN60947-7-1.
Advantage
The terminal can be installed on the TH35 or G32 type guide rail, and also be on the plate.
Adopts plate connection.
Has an insulating part, such as clapboard, grouping separator and septa.
Has a safe dust cover
SN-50W
| type | SN-50W |
| L/W/H | 15.5*48*42.5 mm |
| Wire Range | AWG 16-6 |
| Rated current | 50 A |
| Rated voltage | 600 V |
| Section | 14 mm2 |
| Maximum Current | 100 A |
| Screw Type | M5 |
| Cover | SNE-50W |
| Dust Cover | SN-50F |
| Marker | ZBN |
| Packing unit | 60 STK |
| Minimum Order Quantity | 60 STK |
| Weight of each(not include packing box) | 31 g |
Wiring Diagram
More Advantage
The terminal block can be installed on the TH35 rail
Use the bridge and jumper can easy to distribute potential.
Dimension
Packing Information
| Packing unit | 60 STK |
| Minimum Order Quantity | 60 STK |
| Weight of each(not include packing box) | 31g |
Specification
| L/W/H | 15.5*48*42.5 mm |
| Wire range | AWG 16-6 |
| Rated current | 50 A |
| Rated voltage | 600 V |
| Color | Black |
| Insulating material | PC |
| Connection type | Screw |
| Wire section | 14 mm2 |
| Maximum current | 70 A |
| Screw type | M5 |
| Cover | SNE-50W |
| Dust cover | SN-50F |
